3M
5491
PTFE Extruded Film Tape
5491 is a 6.5 mil. extruded PTFE (polytetrafluorethylene) film backing with a silicone adhesive is primarily used for sealing and masking, wrapping applications and application of an easy release surface on substrates. Tape 5490 and 5491 are extruded, calendered film tapes that provide an exceptionally smooth surface when applied and resist curling during unwind. Extruded PTFE film tapes lie flatter than typical skived PTFE film tapes. The backing of tape 5491 helps extend the service life of the tape when subjected to abrasion or wear. Chemical resistance of tape 5490 and 5491 is excellent except to organic solvents.
Converting Services
- Precision Cutting
- Die Cutting
- Slitting
- Printing
- Laminating and Coating
- Spooling and Finishing
- Consulting & Process Audit
- Prototyping
- Inventory Management
At Budnick, we specialize in custom converting these materials into labor saving, user-friendly parts.
| Backing/Carrier | PTFE - Extruded |
|---|---|
| Adhesive | Silicone |
| Thickness | 6.5 Mils |
| Tensile | 40.00 lbs/in |
|---|---|
| Elongation | 200.00% |
| Adhesive Activation | Pressure |
| Adhesion (unwind) | 35 oz/in |
| Min. Application Temp | 50° F |
|---|---|
| Min. Service Temp | -65° F |
| Max Short-Term Temp | 400° F |
| Max Long-Term Temp | 450° F |
Product Features
- Extruded PTFE film is low coefficient of friction
- Extruded PTFE film is easy release
- Extruded PTFE film lays flat
- Extruded PTFE film high mechanical strength
- Silicone adhesive has high temperature performance
- Silicone adhesive has long aging properties
- Improves movement of materials
- Minimizes clean-up of viscous substances
- Stays put; minimizes rework
- Durable
- Increases productivity
Adhesive Tape Applications
- Easy release surface on rollers, plates, belts, etc. where build up of sticky materials and inks can occur
- Low coefficient of friction surface on rollers, formers, etc. to facilitate web movement
- Chemcial resistant surface for sealing and masking
- Wrapping rubber nip rollers on hot polyethylene extrusion machines
Adhesive Tape Colors
- Gray
Comparable Products
Data provided by Budnick Converting, Inc.
The physical properties listed are typical values and are not to be considered as specifications. Our suggestions for use are based on tests we believe to be reliable. However, the purchaser must carry out their own tests to determine the suitability of the product for their internal use. Information is given in good faith, but without warranty.
It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied be clean, dry and free of grease and oil.
Shelf life from date of manufacture is based on the product being stored at 70°F(21°C) / 50% relative humidity out of direct sunlight.
Specification compliance is dynamic and should only be used as a general guide. Always confirm that the tape you are interested in currently complies with all specification requirements. Please verify that the product number that you select is available in the proper size and color to meet your specification.
