C501-12PT
Polyester Supported Laminating Adhesive
C501-12PT is a supported, high performance laminating adhesive designed for high performance automotive foam fabricating applications bonded to polypropylene, polyethylene, TEO, and TPO. The unwind side is coated with our MP33 foam bonding adhesive which exhibits excellent adhesion to ether and ester urethane foams. The liner side is coated with a high molecular weight synthetic rubber based adhesive that bonds well to high and low surface energy substrates and exhibits excellent shear strength. C501-12PT is recommended for wrap-around applications where heat resistance is required. The adhesive has been certified to Ford specification ESP-M3G76-B2 and General Motors GM3622M type IV.
Converting Services
- Precision Cutting
- Die Cutting
- Slitting
- Printing
- Laminating and Coating
- Spooling and Finishing
- Consulting & Process Audit
- Prototyping
- Inventory Management
At Budnick, we specialize in custom converting these materials into labor saving, user-friendly parts.
| Backing/Carrier | PET - Polyester |
|---|---|
| Adhesive | Acrylic |
| Thickness | 4.3 Mils |
| Tensile | |
|---|---|
| Elongation | |
| Adhesion (liner) | 130 oz/in |
| Adhesion (unwind) | 665 oz/in |
| Min. Application Temp | 50° F |
|---|---|
| Min. Service Temp | -35° F |
| Max Short-Term Temp | 225° F |
| Max Long-Term Temp | 180° F |
Product Features
- Certified to Ford sepcification ESB-M3G76-B2 and General Motors GM3622M type IV
Markets Served
- Automotive
- Industrial
Adhesive Tape Applications
- Wrap around application where heat resistance is required
- High performanc automotive foam fabricating
Data provided by Budnick Converting, Inc.
The physical properties listed are typical values and are not to be considered as specifications. Our suggestions for use are based on tests we believe to be reliable. However, the purchaser must carry out their own tests to determine the suitability of the product for their internal use. Information is given in good faith, but without warranty.
It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied be clean, dry and free of grease and oil.
Shelf life from date of manufacture is based on the product being stored at 70°F(21°C) / 50% relative humidity out of direct sunlight.
Specification compliance is dynamic and should only be used as a general guide. Always confirm that the tape you are interested in currently complies with all specification requirements. Please verify that the product number that you select is available in the proper size and color to meet your specification.
