C690B-12PT
3.4 mil Polyester Supported Laminating Adhesive
C690B-12PT is a general purpose, high performance polyester supported laminating adhesive designed for automotive applications where low density ether or ester urethane foams are bonded to polypropylene, polyethylene, TEO, and TPO. The foam bonding side is a specially formulated adhesive which exhibits excellent adhesion to ether and ester urethane foams. The liner side is coated with a high temperature synthetic rubber base which exhibits excellent adhesion to low surface energy substrates. biocide has been added to the adhesive to meet Ford specification ES-D8VH-19A672AA. This product has been certified to meet the adhesive performance requirements of Ford specification ESA-M11P19-B and GM specification 3622M.
Converting Services
- Precision Cutting
- Die Cutting
- Slitting
- Printing
- Laminating and Coating
- Spooling and Finishing
- Consulting & Process Audit
- Prototyping
- Inventory Management
At Budnick, we specialize in custom converting these materials into labor saving, user-friendly parts.
| Backing/Carrier | PET - Polyester |
|---|---|
| Adhesive | Acrylic |
| Thickness | 3.45 Mils |
| Tensile | |
|---|---|
| Elongation | |
| Adhesion (liner) | 130 oz/in |
| Adhesion (unwind) | 65 oz/in |
| Min. Application Temp | 50° F |
|---|---|
| Min. Service Temp | -35° F |
| Max Short-Term Temp | 185° F |
| Max Long-Term Temp | 135° F |
Product Features
- Biocide has been added to the adhesive to meet Ford specification ES-D8VH-19A672AA
- Certified to meet requirements of Ford specification ESA-M11P19-B and GM specification 3622M
Markets Served
- Automotive
Adhesive Tape Applications
- Automotive applications bonding low density foams to polypropylene, polyethylene, TEO and TPO
Data provided by Budnick Converting, Inc.
The physical properties listed are typical values and are not to be considered as specifications. Our suggestions for use are based on tests we believe to be reliable. However, the purchaser must carry out their own tests to determine the suitability of the product for their internal use. Information is given in good faith, but without warranty.
It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied be clean, dry and free of grease and oil.
Shelf life from date of manufacture is based on the product being stored at 70°F(21°C) / 50% relative humidity out of direct sunlight.
Specification compliance is dynamic and should only be used as a general guide. Always confirm that the tape you are interested in currently complies with all specification requirements. Please verify that the product number that you select is available in the proper size and color to meet your specification.
