F5227Z-STD
Unsupported Low-Fogging Laminating Adhesive
F5227Z-STD is a high performance, 4.5 mil unsupported acrylic free-film designed for laminating to fabric type substrates, such as automotive flock. F5227Z-STD exhibits excellent adhesion to a wide variety of substrates and has very good resistance to heat, humidity, solvents, and mild plasticizers. The MP27 adhesive has been tested and passed requirements for several low-fogging automotive standards. As with all high performance applications it is imperative that each application be thoroughly evaluated prior to use.
Converting Services
- Precision Cutting
- Die Cutting
- Slitting
- Printing
- Laminating and Coating
- Spooling and Finishing
- Consulting & Process Audit
- Prototyping
- Inventory Management
At Budnick, we specialize in custom converting these materials into labor saving, user-friendly parts.
| Backing/Carrier | |
|---|---|
| Adhesive | Acrylic |
| Thickness |
| Tensile | |
|---|---|
| Elongation | |
| Adhesive Activation | Pressure |
| Adhesion (unwind) | 140 oz/in |
| Min. Application Temp | 50° F |
|---|---|
| Min. Service Temp | -35° F |
| Max Short-Term Temp | 325° F |
| Max Long-Term Temp | 250° F |
Product Features
- Very good resistance to heat, humidity, solvents, and mild plasticizers
- Tested to and passed requirements for several low-fogging automotive standards
Markets Served
- Automotive
- Aerospace
- Marine
- Recreational
Adhesive Tape Applications
- Laminating to fabric-type substrates such as automotive flock
Data provided by Budnick Converting, Inc.
The physical properties listed are typical values and are not to be considered as specifications. Our suggestions for use are based on tests we believe to be reliable. However, the purchaser must carry out their own tests to determine the suitability of the product for their internal use. Information is given in good faith, but without warranty.
It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied be clean, dry and free of grease and oil.
Shelf life from date of manufacture is based on the product being stored at 70°F(21°C) / 50% relative humidity out of direct sunlight.
Specification compliance is dynamic and should only be used as a general guide. Always confirm that the tape you are interested in currently complies with all specification requirements. Please verify that the product number that you select is available in the proper size and color to meet your specification.
