Budnick Converting ®
3M
VHB™ Tape LSE-060WF
High Bond Acrylic Foam Tape for Low Surface Energy
3M™ VHB™ Tape LSE-060WF. It is a white, 25 mil thick, double sided high bond tape with a modified acrylic adhesive on both sides of a conformable foam core. It can replace rivets, welds and screws as well as other forms of mechanical fasteners. The 3M VHB Tape LSE Series masters the challenge of low surface energy (LSE) bonding and delivers durable results where other bonding solutions need additional support on special surface treatment. It offers a superior bonding performance without primer on difficult to bond substrates such as PP, TPO, TPE, and composite materials. By eliminating the need for priming in your production, the LSE Series increases productivity and reduces the use of harmful chemicals in your facilities. Excellent durability including its wide temperature resistance ensure ultimate performance strength and reliability for in- and outdoor applications. The fast and easy to use permanent bonding method provides high strength and offers design flexibility with its viscoelasticity, making it an ideal fit for multi material bonding due to his properties on thermal expansion.
Converting Services
- Precision Cutting
- Die Cutting
- Slitting
- Printing
- Laminating and Coating
- Spooling and Finishing
- Consulting & Process Audit
- Prototyping
- Inventory Management
At Budnick, we specialize in custom converting these materials into labor saving, user-friendly parts.
| Backing/Carrier | Acrylic Foam |
|---|---|
| Adhesive | Acrylic |
| Thickness | 25 Mils |
| Tensile | 80.00 lbs/in |
|---|---|
| Elongation | |
| Adhesion (liner) | |
| Adhesion (unwind) | 42.5 oz/in |
| Min. Application Temp | 50° F |
|---|---|
| Min. Service Temp | |
| Max Short-Term Temp | 300° F |
| Max Long-Term Temp | 194° F |
Product Features
- Fast and easy-to-use permanent bonding method provides high strength and long-term durability indoors and outdoors
- Pressure sensitive adhesive bonds on contact to provide immediate handling strength
- Virtually invisible fastening keeps surfaces smooth
- White, 0.025” (0.6 mm), modified acrylic adhesive and conformable acrylic foam core for LSE bonding without primer
- Can replace mechanical fasteners (rivets, welding, screws) or liquid adhesives: Eliminate drilling, grinding, refinishing, screwing, welding and clean-up
- Viscoelastic foam provides dynamic stress absorption to reduce vibration and impact stress
- Creates a permanent seal against water, moisture and more
- Can eliminate the need for priming on many plastics and composites, increasing productivity and reducing the use of chemicals
Markets Served
- Automotive
- Appliance
- Construction
- Truck and trailer body
- Signage, Banners, & Printing
- Marine
- Industrial
- Extruders of Plastic and Rubber
- Aerospace
Adhesive Tape Applications
- Permanent bonding and mounting applications
- Bonding and sealing of panel to frame and stiffener to panel applications especially in transportation, signage and appliances markets
- Capability to bond to many LSE substrates without primer makes it a good fit for applications in many industries such as plastics processing, transportation, appliances and signage
Adhesive Tape Colors
- White
Data provided by Budnick Converting, Inc.
The physical properties listed are typical values and are not to be considered as specifications. Our suggestions for use are based on tests we believe to be reliable. However, the purchaser must carry out their own tests to determine the suitability of the product for their internal use. Information is given in good faith, but without warranty.
It is essential, as with all pressure-sensitive tapes, that the surface to which the tape is applied be clean, dry and free of grease and oil.
Shelf life from date of manufacture is based on the product being stored at 70°F(21°C) / 50% relative humidity out of direct sunlight.
Specification compliance is dynamic and should only be used as a general guide. Always confirm that the tape you are interested in currently complies with all specification requirements. Please verify that the product number that you select is available in the proper size and color to meet your specification.
